Moore’s Law Extended.

Moore’s Law (the doubling of transistor density on a chip every 18 months) has driven the semiconductor industry for decades, but the era of scaling geometries down is coming to an end due to physics and economics.

CrossFire solves the interconnection, integration, density, and manufacturing challenges required to enable design engineers to go beyond scaling chip features, and scale system functionality. CrossFire’s first product offering based on its core technologies is the Xilinx MPSoC-based SiP (System-in Package) family of devices

Get a technical presentation

Screen Shot 2019-02-03 at 12.08.32 PM.jpg

Delivering Small Solutions to Big Semiconductor Design Challenges

CrossFire’s technology platform enables design engineers to develop complex microelectronic systems that integrate multiple semiconductor die (SoCs, FPGAs, DRAM/Flash memories, and power or passive devices) into a single electronic component with higher density, lower development costs, and faster time to market than conventional semiconductor technology.

Faster time to market means faster time to revenue

Using CrossFire’s patented design platform, design cycles for prototypes and production occur in weeks instead of months, enabling the acceleration of software development without manufacturing bottlenecks.

Lower development costs deliver higher profit margins

CrossFire’s integration technology enables the use of existing IP blocks to develop a complex microscale SoM at a fraction of the cost of conventional SoC development.

Higher integration lowers component count & interconnect power consumption

An overall system size reduction of 10x is possible, with a corresponding reduction in interconnect power consumption. Lower component count means a streamlined supply chain and simpler designs.

Contact us to find out how CrossFire’s technology platform can innovate, integrate, and accelerate your next design.
